Features
- TVI/AHD/CVI/CVBS/IPCfive-in-one function, multi-mode input, support HD analog video encoding, support HD analog + HD network video input, support pure HD network video input.
- Easily implement network penetration through cloud services and remote monitoring in one step.
- Supports various mobile phone monitoring (iPhone/Android).
- Support multiple web browsers (IE/Chrome/Firefox/Safari).
- Support VGA, TV, HDMI output at the same time.
- Powerful network services (supporting DHCP, PPPOE,FTP, DNS, DDNS, NTP, UPNP, Email, etc.), complete supporting facilities (WEB, client, SDK), easily achieve interconnection and interoperability.
- Supports more than 20 languages and breaks the limits of national borders.
- Freely change the startup interface and choose the interface style.
- Support human function.
- Support STVI function.
- Support coaxial audio.
- Support TS Cloud cloud platform customization.
Technical parameters
| Model | TVB9704C_F2 | |
| system | Master chip | HI3521A |
| AD chip | TP2830 | |
| RAM | 2G | |
| Compression format | H.265X | |
| operating system | Linux | |
| video | Input | 4 |
| Preview | 4*5MN@20fps | |
| Coding | 4*5MN@12fps | |
| Decoding | 2*5MN@12fps | |
| Channel mode | Support any channel mode combination (5MN analog + 1080P digital) | |
| VGA output | 1080P | |
| BNC output | support | |
| HDMI output | 1080P | |
| Audio | Audio Input | 4 |
| Audio output | 1 | |
| Coaxial audio | 4 | |
| Record | Real-time video channels | 4-way non-real-time |
| Video mode | Timing, manual, motion detection, external alarm | |
| Playback | Simultaneous playback | 2 |
| Search mode | Point-in-time search, calendar search, event search, channel search | |
| Backup | USB mobile hard disk, U disk | support |
| USB DVD burner | support | |
| Format | H26X、AVI | |
| remote access | Browser | Supports multiple web browsers |
| Client | Support VMS | |
| APP | Support for iPhone, Android | |
| storage | HDD number | 1 |
| E-SATA | not support | |
| Network | Network port | 10/100MbpsRJ-45) |
| Network protocol | TCP/IP, DHCP, DDNS, NTP, SMTP | |
| other | remote control | support |
| power supply | DC12V/2A | |
| Work Temperature | -10℃~60℃ | |
| Working humidity | 10%~90% Humidity |
